Lifting capacity |
32ton |
Total power |
33.9kw |
|
|
Lifting height |
12.5m |
Max wheel load |
338.5KN |
|
|
Crane Span |
26m |
Working duty |
A3 |
|
|
Cantilevers |
Left 8m, right 8m |
Power supply |
380v, 3phase |
|
|
Hoist type |
Electric Wire Rope Hoist |
Remote control |
Pendant with cable |
|
|
Lifting speed |
3m/min |
Insulation class |
F |
|
|
Cross traveling speed |
16m/min |
Bearings |
LYC |
|
|
Long traveling speed |
77.5m/min |
Wire rope core |
Fibre |
|
|
Lifting power |
18.5kw |
Overload limiter |
include |
|
|
Cross traveling power |
2*2.2kw |
Track type |
43# |
|
|
Long traveling power |
2*5.5kw |
Weight |
36ton |
|
